| R5F100JLDFA#30 | |
|---|---|
| Part Number | R5F100JLDFA#30 |
| Manufacturer | Renesas Electronics America Inc |
| Description | IC MCU 16BIT 512KB FLASH 52LQFP |
| Quantity Available | 29124 pcs new original in stock. Request Stock & Quotation |
| Datasheets | R5F100JLDFA#30.pdf |
| R5F100JLDFA#30 Price |
Request Price & Lead Time Online or Email us: Info@ariat-tech.com |
| Technical Information of R5F100JLDFA#30 | |||
|---|---|---|---|
| Manufacturer Part Number | R5F100JLDFA#30 | Category | Integrated Circuits (ICs) |
| Manufacturer | Renesas Electronics Corporation | Description | IC MCU 16BIT 512KB FLASH 52LQFP |
| Package / Case | 52-LQFP (10x10) | Quantity Available | 29124 pcs |
| Voltage - Supply (Vcc/Vdd) | 1.6V ~ 5.5V | Supplier Device Package | 52-LQFP (10x10) |
| Speed | 32MHz | Series | RL78/G13 |
| RAM Size | 32K x 8 | Program Memory Type | FLASH |
| Program Memory Size | 512KB (512K x 8) | Product Status | Active |
| Peripherals | DMA, LVD, POR, PWM, WDT | Package / Case | 52-LQFP |
| Package | Tray | Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) | Number of I/O | 38 |
| Mounting Type | Surface Mount | EEPROM Size | 8K x 8 |
| Data Converters | A/D 12x8/10b | Core Size | 16-Bit |
| Core Processor | RL78 | Connectivity | CSI, I²C, LINbus, UART/USART |
| Base Product Number | R5F100 |
Manufacturer Part Number
R5F100JLDFA#30
Description
16-bit microcontroller with 512KB Flash memory in a 52-LQFP package. Features RL78/G13 core running at 32MHz. Designed for embedded systems needing multiple serial interfaces and flexible peripherals.
Specifications
Core: RL78, 16-bit
Operating Frequency: 32MHz
Program Memory: 512KB Flash
EEPROM: 8KB
RAM: 32KB
Number of I/O Pins: 38
Data Converter: 12-channel 8/10-bit ADC
Connectivity: CSI, I2C, LINbus, UART/USART
Peripherals: DMA, LVD, POR, PWM, WDT
Voltage Supply: 1.6V to 5.5V
Oscillator: Internal
Operating Temp: -40°C to 85°C
Package Type: 52-LQFP (10x10mm)
Mounting: Surface Mount
MSL: Level 3 (168 hours)
RoHS Status: Compliant
REACH Status: Unaffected
ECCN: 3A991A2
HTSUS: 8542.31.0001
Device Structure
Monolithic single-chip microcontroller including CPU core, memory blocks, analog/digital converters, clock circuit, and multiple connectivity ports integrated into a 52-pin LQFP plastic package.
Performance Characteristics
Fast processing at up to 32MHz
Large Flash program storage (512KB), suitable for complex applications
Wide supply voltage for flexible power options
Reliable operation in industrial temperature ranges (-40°C ~ 85°C)
Multiple communication ports and advanced peripherals for real-time control
Internal oscillator simplifies external component requirements
Supports low power consumption modes
Application Environments
Can be used in home appliances, industrial automation, medical electronics, consumer products, and automotive electronic systems requiring mid-level processing power, extensive I/O, and robust serial connectivity.
Selection Guidelines
Choose this model for demanding embedded tasks needing high code space (512KB), many I/O lines (38), and advanced serial interfaces (CSI, I2C, UART, LINbus). Check compatibility with 52-LQFP footprint in your PCB. Ensure the 32MHz clock speed and required voltage range fits system needs. Select RL78/G13 series if existing code base or peripheral requirements match.
Usage Considerations
Proper handling required for MSL Level 3 moisture sensitivity, reflow soldering within 168 hours after opening package. Confirm supply voltage and temperature range with your application environment. Monitor ADC accuracy and pin assignments for analog sensors. Observe design best practices for surface-mounted MCUs. Follow RoHS and REACH compliance for global shipments.
Potential Equivalent/Replacement Models
There are direct alternate models:
R5F100JLAFA#30
R5F100JLAFA#10
R5F100JLDFA#10
Please check detailed datasheets for pinout, memory, or peripheral differences. If these alternatives do not fit your requirements, contact the Ariat-Tech sales team for more model options and expert problem-solving.
Email us: Info@Ariat-Tech.com or RFQ R5F100JLDFA#30 Online.
