| MCIMX6S5DVM10AB | |
|---|---|
| Part Number | MCIMX6S5DVM10AB |
| Manufacturer | NXP USA Inc. |
| Description | IC MPU I.MX6S 1.0GHZ 624MAPBGA |
| Quantity Available | 825 pcs new original in stock. Request Stock & Quotation |
| Datasheets | 1.MCIMX6S5DVM10AB.pdf2.MCIMX6S5DVM10AB.pdf3.MCIMX6S5DVM10AB.pdf4.MCIMX6S5DVM10AB.pdf5.MCIMX6S5DVM10AB.pdf6.MCIMX6S5DVM10AB.pdf7.MCIMX6S5DVM10AB.pdf8.MCIMX6S5DVM10AB.pdf9.MCIMX6S5DVM10AB.pdf |
| Download | MCIMX6S5DVM10AB Details PDF |
| MCIMX6S5DVM10AB Price |
Request Price & Lead Time Online or Email us: Info@ariat-tech.com |
| Technical Information of MCIMX6S5DVM10AB | |||
|---|---|---|---|
| Manufacturer Part Number | MCIMX6S5DVM10AB | Category | Integrated Circuits (ICs) |
| Manufacturer | NXP USA Inc. | Description | IC MPU I.MX6S 1.0GHZ 624MAPBGA |
| Package / Case | 624-MAPBGA (21x21) | Quantity Available | 825 pcs |
| Voltage - I/O | 1.8V, 2.5V, 2.8V, 3.3V | USB | USB 2.0 + PHY (4) |
| Supplier Device Package | 624-MAPBGA (21x21) | Speed | 1.0GHz |
| Series | i.MX6S | Security Features | ARM TZ, Boot Security, Cryptography, RTIC, Secure Fusebox, Secure JTAG, Secure Memory, Secure RTC, Tamper Detection |
| SATA | - | RAM Controllers | LPDDR2, LVDDR3, DDR3 |
| Package / Case | 624-LFBGA | Package | Tray |
| Operating Temperature | 0°C ~ 95°C (TJ) | Number of Cores/Bus Width | 1 Core, 32-Bit |
| Mounting Type | Surface Mount | Graphics Acceleration | Yes |
| Ethernet | 10/100/1000Mbps (1) | Display & Interface Controllers | Keypad, LCD |
| Core Processor | ARM® Cortex®-A9 | Co-Processors/DSP | Multimedia; NEON™ SIMD |
| Base Product Number | MCIMX6 | Additional Interfaces | CAN, I²C, I²S, MMC/SD/SDIO, SAI, SPI, SSI, UART |
| Download | MCIMX6S5DVM10AB PDF - DE.pdfMCIMX6S5DVM10AB PDF - FR.pdfMCIMX6S5DVM10AB PDF - IT.pdfMCIMX6S5DVM10AB PDF - KR.pdfMCIMX6S5DVM10AB PDF - ES.pdf | ||
Product Model
MCIMX6S5DVM10AB
Introduction
NXP i.MX6S Microprocessor for multimedia applications
Brand and Manufacturer
NXP Semiconductors / Freescale
Features
ARM Cortex-A9 core
1.0GHz operating speed
Single core, 32-bit architecture
Integrated multimedia co-processors
NEON SIMD extensions support
Product Performance
Efficient ARM Cortex-A9 processing at 1GHz
High-definition graphics and video acceleration
Supports complex, graphics-intensive user interfaces
Technical Specifications
Voltage - I/O: 1.8V, 2.5V, 2.8V, 3.3V
624-LFBGA package, 624-MAPBGA (21x21) device package
Dimensions, Shape, and Packaging
21x21 mm MAPBGA package
Shipped in trays
Quality and Reliability
High-quality parts from NXP
Robust reliability for industrial applications
Product Advantages
Supports a variety of RAM types (LPDDR2, LVDDR3, DDR3)
On-chip security features
Advanced multimedia support
Product Competitiveness
Cost-effective single-core solution
Secure and versatile for a wide range of applications
Compatibility
Multiple Voltage I/O support for diverse system design
USB, Ethernet, and additional interfaces for peripherals
Standard Certification and Compliance
Certified by industry standards for integrated circuits
Lifespan and Sustainability
Designed for extended life in embedded applications
Actual Application Fields
Consumer electronics
Automotive infotainment
Industrial automation
Smart devices
Internet of Things (IoT)
Email us: Info@Ariat-Tech.com or RFQ MCIMX6S5DVM10AB Online.
