Manufacturer Part Number

BZT52C5V1-7-F

Description

Zener diode for voltage regulation. 5.1V nominal Zener voltage with 500mW power handling. Housed in small SOD-123 package for compact circuit designs. Surface mount type for easy PCB integration. Works well for overvoltage protection and reference voltage stabilization in circuits. Designed for precision with ±6% tolerance. Suitable for various electronics applications needing stable low voltage.

Specifications

Nominal Zener Voltage: 5.1 V

Power Dissipation: 500 mW max

Tolerance: ±6%

Maximum Zener Impedance: 60 Ω

Reverse Leakage Current: 2 µA at 2 V

Maximum Forward Voltage: 900 mV at 10 mA

Operating Temperature: -65°C to +150°C

Package: SOD-123, surface mount

Moisture Sensitivity: Level 1, unlimited

RoHS3 compliant, REACH unaffected

Status: Active, in production

Inventory: 110,400 pieces, new and original in stock

Device Structure

Single Zener diode chip engineered for surface mounting. SOD-123 case provides compact footprint and good thermal performance. Designed for efficient heat dissipation in PCB layouts. Simple construction suitable for automated assembly.

Performance Characteristics

Offers stable breakdown voltage at 5.1 V with low leakage and tight tolerance. Maintains reliable operation up to 500mW power dissipation. Low forward voltage drop allows efficient power use. Can operate in wide temperature range without performance loss. Maximum impedance of 60 Ohms ensures consistent voltage regulation. Very low reverse leakage current reduces power waste.

Application Environments

Commonly used in consumer electronics, industrial controls, telecommunications, and automotive systems. Suitable for voltage reference, voltage protection, or simple regulation. Good choice for densely populated PCBs and portable devices. Operates well in harsh environments due to wide temperature range. Approved for applications requiring RoHS and REACH compliance.

Selection Guidelines

Choose this model when you need 5.1V regulation with moderate power handling. Consider SOD-123 packaging for space-limited designs. Make sure the 500mW max power is sufficient for your application. Check if ±6% voltage tolerance matches your circuit needs. Evaluate operating temperature needs for your application environment. For higher power or different voltage, select appropriate alternative models.

Usage Considerations

Ensure proper heat dissipation on PCB to avoid exceeding 500mW limit. Verify SOD-123 pad layout is compatible with your assembly process. Respect maximum reverse leakage and impedance ratings for reliable circuit operation. Store in recommended environment; low moisture sensitivity (MSL 1) allows easier handling in manufacturing. Confirm compliance requirements for RoHS and REACH.

Potential Equivalent/Replacement Models

There are equivalent or alternative models available. Common replacements include similar Zener diodes from other manufacturers, such as:

Vishay: MMSZ5231B (5.1V, SOD-123)

ON Semiconductor: MM3Z5V1T1G (5.1V, SOD-323)

Nexperia: BZX384-C5V1 (5.1V, SOD-323)

ROHM: UDZV5.1B (5.1V, SOD-323)

If you need exact pin compatibility or package matching, check the datasheets and PCB footprint. For other alternatives or custom requirements, please contact the Ariat-Tech sales team for more information.
