| ACPL-W50L-560E | |
|---|---|
| Part Number | ACPL-W50L-560E |
| Manufacturer | Broadcom Limited |
| Description | OPTOISO 5KV TRANS 6-SO STRETCHED |
| Quantity Available | 17203 pcs new original in stock. Request Stock & Quotation |
| Datasheets | 1.ACPL-W50L-560E.pdf2.ACPL-W50L-560E.pdf3.ACPL-W50L-560E.pdf4.ACPL-W50L-560E.pdf5.ACPL-W50L-560E.pdf |
| Download | ACPL-W50L-560E Details PDF |
| ACPL-W50L-560E Price |
Request Price & Lead Time Online or Email us: Info@ariat-tech.com |
| Technical Information of ACPL-W50L-560E | |||
|---|---|---|---|
| Manufacturer Part Number | ACPL-W50L-560E | Category | Isolators |
| Manufacturer | Avago Technologies (Broadcom) | Description | OPTOISO 5KV TRANS 6-SO STRETCHED |
| Package / Case | 6-SO Stretched | Quantity Available | 17203 pcs |
| Voltage - Output (Max) | 24V | Voltage - Isolation | 5000Vrms |
| Voltage - Forward (Vf) (Typ) | 1.5V | Vce Saturation (Max) | - |
| Turn On / Turn Off Time (Typ) | 200ns, 380ns | Supplier Device Package | 6-SO Stretched |
| Series | - | Rise / Fall Time (Typ) | - |
| Package / Case | 6-SOIC (0.268', 6.80mm Width) | Package | Tape & Reel (TR) |
| Output Type | Transistor | Operating Temperature | -40°C ~ 105°C |
| Number of Channels | 1 | Mounting Type | Surface Mount |
| Input Type | DC | Current Transfer Ratio (Min) | 93% @ 3mA |
| Current Transfer Ratio (Max) | 200% @ 3mA | Current - Output / Channel | 8mA |
| Current - DC Forward (If) (Max) | 20 mA | Base Product Number | ACPL-W50 |
| Download | ACPL-W50L-560E PDF - DE.pdf | ||
Manufacturer Part Number
ACPL-W50L-560E
Description
High-performance, single-channel, optically-isolated transistor output coupler with integrated LEDs for industrial and consumer applications. Provides robust isolation between input and output, high current transfer ratio, and fast switching speeds.
Product Packaging
Tape & Reel (TR) packaging
6-SOIC (0.268", 6.80mm Width) surface mount package
Stretched 6-SO package configuration
Why Choose This Product?
Reliable and robust isolation between input and output
High current transfer ratio for efficient signal transmission
Fast switching speeds enable high-speed operation
Wide operating temperature range for versatile applications
Key Features
Single-channel optoisolator with transistor output
5000Vrms isolation voltage
93% minimum to 200% maximum current transfer ratio
200ns typical turn-on and 380ns typical turn-off time
DC input and transistor output
Product Compatibility
Compatible with a wide range of industrial and consumer electronic applications
Key Advantages
High isolation voltage for safety and reliability
Efficient signal coupling with high current transfer ratio
Fast switching speeds for high-speed operation
Wide operating temperature range for environmental flexibility
Product Lifecycle
This product is currently active and in production
Customers are advised to contact our sales team via the website for information on any equivalent or alternative models that may be available
Key Application Areas
Industrial control and automation
Consumer electronics
Power supplies
Motor drives
Telecommunications equipment
Take Action Now
Get a quote for the ACPL-W50L-560E optoisolator on our website today. Limited time offer - contact us now to learn more about this high-performance product.
Email us: Info@Ariat-Tech.com or RFQ ACPL-W50L-560E Online.
