Manufacturer Part Number

TLV341IDRLR

Description

Single general purpose operational amplifier from Texas Instruments. Features rail-to-rail output and works across a wide supply voltage range. Packaged in a compact SOT-5X3 (SOT-563, SOT-666) for space-saving designs. Great for applications requiring low power, high precision, and high output drive capacity.

Specifications

Single-channel (1 circuit) op amp

Rail-to-rail output type

Slew rate: 1V/µs

Gain bandwidth product: 2.3MHz

Input bias current: 1pA

Input offset voltage: 300µV

Supply current: 75µA

Output current per channel: 115mA

Supply voltage range: 1.5V to 5.5V

Operating temperature: -40°C to 125°C

Surface mount package: SOT-5X3 (SOT-563/666)

RoHS3 Compliant, REACH unaffected

MSL: 1 (unlimited)

ECCN: EAR99

HTSUS: 8542.33.0001

Device Structure

Single operational amplifier in a compact 5-pin SOT-5X3 (SOT-563/SOT-666) package. Designed for surface mounting. Suitable for high-density or portable applications due to its miniature size.

Performance Characteristics

Low power consumption with 75µA supply current

Low input bias current (1pA) allows use in sensitive analog circuits

Low offset voltage (300µV) improves accuracy

Maintains consistent performance across full commercial and industrial temperature range

Rail-to-rail output enables full use of available output swing

High output current capability (up to 115mA) supports more demanding loads

Moderate gain bandwidth (2.3MHz) suitable for most general signal conditioning tasks

Fast enough slew rate (1V/µs) for general analog amplification

Application Environments

General-purpose analog signal amplification

Battery-powered devices and portable electronics

Sensor front-end signal conditioning

Medical instrumentation

Measurement and data acquisition systems

Industrial automation and control systems

Consumer electronics where board space is critical

Low voltage analog circuits

Selection Guidelines

Choose if you need a single op amp with low power and wide supply range

Fits applications needing rail-to-rail output swing at low voltages

Best for designs where board space is limited

Effective when high input impedance and low offset are required

Evaluate gain, bandwidth, and output current against system requirements

Ensure the device fits SOT-5X3 (SOT-563/666) surface-mount footprint

Usage Considerations

Always observe maximum supply voltage (do not exceed 5.5V)

Follow proper handling to avoid static damage

Ensure good PCB layout for analog signals to reduce noise

Check PCB footprint matches SOT-5X3 package

Verify ambient temperature stays within -40°C to 125°C

Pay attention to power dissipation in case of sustained high output current

Evaluate input and output signal levels for proper operation within op amp’s limits

Potential Equivalent/Replacement Models

Several similar single-channel, rail-to-rail op amps are available from Texas Instruments and other suppliers. Detailed compatible alternates could include:

Texas Instruments TLV341IDCKR (same base part, different package SOT-23-5)

Texas Instruments TLV341 (any variant with compatible specifications and preferred package)

Microchip MCP6001, MCP6021 (similar rail-to-rail, low power amplifiers)

Analog Devices ADA4505-1 (pin-compatible, similar specs)

ON Semiconductor MC33201 (alternative with comparable features)

For full drop-in or direct replacement, please check package compatibility and pinout. If no listed models fully meet your system requirements, contact the Ariat-Tech sales team for personalized assistance and more alternative recommendations.
