Manufacturer Part Number

EP4CE30F29C9L

Description

Cyclone IV E series FPGA from Intel. 780-ball fine-pitch BGA package with 532 user IOs. Field Programmable Gate Array class, intended for high-performance embedded processing, custom logic integration, and flexible hardware acceleration. 28,848 logic elements and 608,256 RAM bits for robust logic design and memory storage. Suitable for rapid prototyping, digital signal processing, and system integration. Inventory of 673 units available, new and original, in tray packaging. RoHS non-compliant, REACH unaffected.

Specifications

Series: Cyclone IV E

Logic Elements/Cells: 28,848

Total RAM Bits: 608,256

LABs/CLBs: 1,803

User I/O Pins: 532

Operating Supply Voltage: 0.97V to 1.03V

Operating Temperature Range: 0°C to 85°C TJ

Mounting: Surface mount

Package/Case: 780-BGA (29mm x 29mm footprint)

Moisture Sensitivity Level: MSL 3 (168hrs max exposure)

ECCN: 3A001A7A

HTSUS: 8542.39.0001

RoHS Status: Non-compliant

REACH Status: Unaffected

Device Structure

FPGA device with high-density logic elements for custom hardware implementation. 780-ball BGA package with fine-pitch leads ideal for space-critical applications. 532 available pins for flexible interfacing. Integrated RAM blocks distributed throughout the device. Supports multiple voltage references and bank logic for interfacing with various digital protocols.

Performance Characteristics

Active production status ensures long-term availability. High I/O count and large logic cell numbers suit complex digital processing and multi-signal integration. On-chip memory enables efficient data storage and transfer. Fast signal routing and low power supply range for optimized performance and energy efficiency.

Application Environments

Industrial automation control

Medical instrumentation

Network communications

Consumer electronics

Video and image processing

Test and measurement equipment

Embedded system prototyping

Suitable for environments requiring robust digital signal processing and programmable hardware acceleration.

Selection Guidelines

Verify logic cell and RAM requirements for your design, confirm compatibility with the supply voltage and operating temperature range. Ensure the 780-ball footprint is acceptable for your PCB and manufacturing process. Consider non-compliance with RoHS for regulated markets. Check I/O pin count against your application needs.

Usage Considerations

Sensitive to moisture, follow MSL 3 storage and soldering guidelines. Ensure your PCB design accounts for fine-pitch BGA package for reliable mounting. Non-RoHS compliance may restrict use in certain geographies. Confirm the supply voltage range matches your system requirements. Observe operating temperature limits for longevity and performance.

Potential Equivalent/Replacement Models

Other members of the Cyclone IV E family with similar or close specifications:

EP4CE30F23C7N

EP4CE30F23C8N

EP4CE30F29C7N

EP4CE30F29C8N

EP4CE30F29C9N

EP4CE30F23I7N

EP4CE30F23I8N

Equivalent models may differ in temperature range, package size, or compliance status. No drop-in replacement options may completely match all features; review individual datasheets for differences. If no direct alternatives satisfy your requirements, contact the Ariat-Tech sales team for assistance and the latest substitution details.
