Manufacturer Part Number

74LCX32245G

Description

This is an integrated circuit transceiver from onsemi designed for bidirectional data communication. It is a non-inverting bus transceiver IC operating at 3.6V and packaged in a compact 96-ball Fine Ball Grid Array (FBGA) with the package size 13.5mm by 5.5mm. This IC is ideal for creating low-voltage, high-speed signal transmission paths. The product is now obsolete, and only limited stock is available.

Specifications

Logic Type: Non-inverting transceiver

Number of Elements: 4

Bits per Element: 8

Output Type: Three-State

Voltage Supply Range: 2V to 3.6V

Output Current (High/Low): 24mA each

Operating Temperature: -40°C to +85°C

Mounting Type: Surface mount

Package: 96-LFBGA, 13.5x5.5mm

Moisture Sensitivity: Level 1 (Unlimited)

REACH Status: Unaffected

ECCN: EAR99

HTSUS Code: 8542.39.0001

Device Structure

Organized as a bus transceiver with 4 separate data elements, each 8 bits wide. Enables high-speed data transfer between different sections of a system. Built with CMOS logic using LCX technology for reduced power consumption.

Performance Characteristics

Supports three-state outputs for easy connection to shared buses. Handles 24mA current for both high and low output states. Operates reliably from 2V to 3.6V, suited for both 2.5V and 3.3V logic systems. Functions from -40°C up to +85°C under ambient operating conditions.

Application Environments

Best for memory interface, data conversion, bus communication, logic-level shifting. Used in embedded systems, networking, telecommunication, and industrial automation that require bidirectional data transfer at low voltage.

Selection Guidelines

Choose this IC when you need multiple 8-bit bus transceivers in a single package with non-inverting logic and high drive capability. Suitable for compact designs with space constraints due to FBGA packaging. Use when legacy LCX series compatibility is required.

Usage Considerations

Product is obsolete—best for maintenance or legacy support. Confirm supply voltage within 2V to 3.6V and package footprint compatibility. Handle and assemble according to JEDEC moisture Level 1 instructions. Check three-state output configuration compatibility with your board bus design. Mind package size and pin mapping—FBGA requires accurate PCB layout techniques.

Potential Equivalent/Replacement Models

There are equivalent or alternative models available:

74LVCH32245ABFG8

74LVCH32245ABFG

74LCX16245MTDX

If none of these alternatives meet your needs, please contact the Ariat-Tech sales team directly for further support and recommendations.
