| ADF4158WCCPZ | |
|---|---|
| Part Number | ADF4158WCCPZ |
| Manufacturer | Analog Devices Inc. |
| Description | IC FRACT N SYNTH 24LFCSP |
| Quantity Available | 3552 pcs new original in stock. Request Stock & Quotation |
| Datasheets | ADF4158WCCPZ.pdf |
| Download | ADF4158WCCPZ Details PDF |
| ADF4158WCCPZ Price |
Request Price & Lead Time Online or Email us: Info@ariat-tech.com |
| Technical Information of ADF4158WCCPZ | |||
|---|---|---|---|
| Manufacturer Part Number | ADF4158WCCPZ | Category | Integrated Circuits (ICs) |
| Manufacturer | Analog Devices Inc. | Description | IC FRACT N SYNTH 24LFCSP |
| Package / Case | 24-LFCSP (4x4) | Quantity Available | 3552 pcs |
| Voltage - Supply | 2.7V ~ 3.3V | Type | Fractional N Synthesizer (RF) |
| Supplier Device Package | 24-LFCSP (4x4) | Series | Automotive |
| Ratio - Input:Output | 2:1 | Product Status | Active |
| Package / Case | 24-WFQFN Exposed Pad, CSP | Package | Tray |
| PLL | Yes | Output | Clock |
| Operating Temperature | -40°C ~ 125°C | Number of Circuits | 1 |
| Mounting Type | Surface Mount | Input | CMOS, TTL |
| Frequency - Max | 6.1GHz | Divider/Multiplier | Yes/Yes |
| Differential - Input:Output | Yes/No | Base Product Number | ADF4158 |
| Download | ADF4158WCCPZ PDF - DE.pdfADF4158WCCPZ PDF - FR.pdfADF4158WCCPZ PDF - ES.pdfADF4158WCCPZ PDF - IT.pdfADF4158WCCPZ PDF - KR.pdf | ||
Product Model
ADF4158WCCPZ
Introduction
Analog Devices' ADF4158 is a fractional-N frequency synthesizer.
Brand and Manufacturer
Analog Devices
Features
PLL-based fractional N synthesizer
Integrated VCO
Programmable modulus and phase detector
Programmable charge pump currents
Cycle slip reduction
Product Performance
Maximum output frequency of 6.1 GHz
Fine frequency resolution with fractional-N division
Low phase noise performance
Technical Specifications
Fractional N synthesizer (RF)
PLL input compatible with CMOS, TTL
Clock output
Single circuit design
Input to output ratio set at 2:1
Supports both differential and single-ended inputs and outputs
Dimensions, Shape, and Packaging
Packaging in tray form
24-WFQFN Exposed Pad, CSP package type
Supplier device package 24-LFCSP (4x4)
Quality and Reliability
Designed for automotive grade applications
Operational temperature range from -40°C to 125°C
Product Advantages
Supports wide range frequency synthesis for various applications
Provides high resolution phase-lock loop frequency control
Product Competitiveness
High-performance synthesizer in RF and microwave applications
Compatibility
Compatible with CMOS and TTL signals
Standard Certification and Compliance
Automotive industry standard compliant
RoHS compliant
Lifespan and Sustainability
Suitable for long-term use in automotive temperature environments
Actual Application Fields
Industry applications in wireless infrastructure, test equipment, and automotive systems
