Manufacturer Part Number

72V70200PF

Description

Multiplexer chip for digital logic circuits, 1 x 16:16 configuration. Packaged in a 100-pin TQFP (Thin Quad Flat Pack), size 14x14 mm. Used to select one of several input signals and forward the selected input to a single output line. Can handle up to 16 input and 16 output channels. Designed for high-speed and reliable switching in electronic systems.

Specifications

Voltage supply range: 3V to 3.6V single supply.

Operating temperature range: -40°C to +85°C.

Package type: 100-TQFP (14mm x 14mm).

Moisture sensitivity level: MSL 3 (168 hours).

RoHS status: Non-compliant.

REACH status: Unaffected.

ECCN: EAR99.

HTSUS code: 8542.39.0001.

Series: 72V.

Active manufacturing status.

Inventory: 1086 pieces of new, original stock available.

Device Structure

1 independent multiplexer circuit.

Channels configuration: 1 x 16 inputs, 16 outputs.

Surface mount design for PCB placement.

Flat, square IC package with 100 pins.

Performance Characteristics

Stable operation across wide temperature range.

Low voltage operation for power-sensitive applications.

Support for high-speed logic signal switching.

Reliable digital signal multiplexing in logic systems.

Good thermal and electrical stress tolerance for industrial environments.

Application Environments

Digital communication systems

Data routing and switching equipment

Signal selection devices

Industrial control logic modules

Network infrastructure hardware

Test and measurement systems

Consumer electronics requiring digital I/O switching

Selection Guidelines

Review voltage supply requirements for compatibility.

Verify operating temperature range matches the intended environment.

Check packaging style for suitability on your PCB or assembly lines.

Confirm logic level and signal specification matches your system needs.

Assess inventory and lead times for project schedules.

Make sure RoHS compliance requirements are met for your region.

Usage Considerations

Not compliant with RoHS, may not be suitable for some regions or applications requiring lead-free components.

Surface mount device requires standard SMT assembly processes.

MSL 3 rating means careful handling and storage required to avoid moisture-related damage; limited exposure time out of moisture barrier bag.

Operating within stated voltage and temperature ensures optimal reliability.

Consult datasheet for detailed signal characteristics and pin configuration before design-in.

Potential Equivalent/Replacement Models

There are no direct equivalent or alternative models listed for 72V70200PF within this request.

Please contact Ariat-Tech sales team for advice on possible substitutes or compatible alternatives.

Customers are encouraged to reach out if specific replacement or cross-reference parts are needed for their application.
