| 90148-1110 | |
|---|---|
| Part Number | 90148-1110 |
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN RECEPT HORIZ 10POS .100 PCB |
| Quantity Available | 20239 pcs new original in stock. Request Stock & Quotation |
| Datasheets | 90148-1110.pdf |
| 90148-1110 Price |
Request Price & Lead Time Online or Email us: Info@ariat-tech.com |
| Technical Information of 90148-1110 | |||
|---|---|---|---|
| Manufacturer Part Number | 90148-1110 | Category | Connectors, Interconnects |
| Manufacturer | Affinity Medical Technologies - Molex | Description | CONN RECEPT HORIZ 10POS .100 PCB |
| Package / Case | Quantity Available | 20239 pcs | |
| Voltage Rating | 350V | Termination | Solder |
| Style | Board to Board | Standard Package | 1 |
| Series | C-Grid 90148 | Row Spacing - Mating | - |
| Pitch - Mating | 0.100" (2.54mm) | Part Status | Active |
| Packaging | Tube | Other Names | 090148-1110 090148-1110-E 0901481110 0901481110-E 90148-1110-E 90148-1110-ND 901481110 901481110-E WM6584 |
| Operating Temperature | -55°C ~ 105°C | Number of Rows | 1 |
| Number of Positions Loaded | All | Number of Positions | 10 |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | - | Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | Insulation Height | 0.130" (3.30mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | 10 Position Receptacle Connector 0.100" (2.54mm) Through Hole, Right Angle Tin | Current Rating | 3A |
| Contact Type | Female Socket | Contact Shape | Square |
| Contact Material | Phosphor Bronze | Contact Length - Post | 0.114" (2.90mm) |
| Contact Finish Thickness - Post | 40.0µin (1.02µm) | Contact Finish Thickness - Mating | 40.0µin (1.02µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Tin |
| Connector Type | Receptacle | Applications | Automotive, General Purpose, Lighting, Medical, Telecommunications |
