| STTH2R02U | |
|---|---|
| Part Number | STTH2R02U |
| Manufacturer | STMicroelectronics |
| Description | DIODE GEN PURP 200V 2A SMB |
| Quantity Available | 43120 pcs new original in stock. Request Stock & Quotation |
| Datasheets | 1.STTH2R02U.pdf2.STTH2R02U.pdf3.STTH2R02U.pdf |
| Download | STTH2R02U Details PDF |
| STTH2R02U Price |
Request Price & Lead Time Online or Email us: Info@ariat-tech.com |
| Technical Information of STTH2R02U | |||
|---|---|---|---|
| Manufacturer Part Number | STTH2R02U | Category | Discrete Semiconductor |
| Manufacturer | STMicroelectronics | Description | DIODE GEN PURP 200V 2A SMB |
| Package / Case | SMB | Quantity Available | 43120 pcs |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 2 A | Voltage - DC Reverse (Vr) (Max) | 200 V |
| Technology | Standard | Supplier Device Package | SMB |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Series | - |
| Reverse Recovery Time (trr) | 30 ns | Product Status | Active |
| Package / Case | DO-214AA, SMB | Package | Tape & Reel (TR) |
| Operating Temperature - Junction | 175°C (Max) | Mounting Type | Surface Mount |
| Current - Reverse Leakage @ Vr | 3 µA @ 200 V | Current - Average Rectified (Io) | 2A |
| Capacitance @ Vr, F | - | Base Product Number | STTH2 |
| Download | STTH2R02U PDF - DE.pdfSTTH2R02U PDF - FR.pdfSTTH2R02U PDF - ES.pdfSTTH2R02U PDF - IT.pdfSTTH2R02U PDF - KR.pdf | ||
Product Model
STTH2R02U
Introduction
Ultra-fast recovery rectifier diode
Brand and Manufacturer
STMicroelectronics
Features
Standard diode type
Fast recovery speed
Product Performance
Average rectified current 2A
Maximum forward voltage 1V at 2A
Reverse leakage current 3μA at 200V
Technical Specifications
Surface mount package DO-214AA, SMB
Maximum DC reverse voltage 200V
Reverse recovery time 30ns
Junction operating temperature up to 175°C
Dimensions, Shape, and Packaging
SMB form factor
Supplied in Cut Tape
Quality and Reliability
High junction temperature tolerance
Moisture Sensitivity Level 1
Product Advantages
Suitable for high-temperature environments
Fast switching capabilities
Product Competitiveness
Well-suited for high-efficiency applications
Compatibility
RoHS compliant
Suitable for surface mount technology
Standard Certification and Compliance
Lead-free, RoHS Compliant
Lifespan and Sustainability
Durable construction for extended lifespan
Actual Application Fields
Power management systems
Switching power supplies
Converters
High-frequency rectifiers
Free Wheeling diodes in converters and motor control circuits
Email us: Info@Ariat-Tech.com or RFQ STTH2R02U Online.
