Manufacturer Part Number

MAX3237EIDB

Description

IC transceiver full RS232, 5 drivers and 3 receivers, supports full-duplex operation. Comes in a compact 28-SSOP package (surface mount). Designed for high-speed RS232 communication. Suitable for replacement of standard RS232 transceivers with improved features.

Specifications

Protocol: RS232

Number of drivers: 5

Number of receivers: 3

Duplex: Full

Receiver hysteresis: 500 mV (better noise immunity)

Data rate: Up to 1 Mbps

Operating voltage: 3V to 5.5V

Operating temperature range: -40°C to +85°C

Physical package: 28-SSOP, 0.209" (5.30 mm width)

Moisture sensitivity level (MSL): 1 (unlimited)

RoHS status: Compliant (ROHS3)

REACH status: Unaffected

ECCN code: EAR99

HTSUS code: 8542.39.0001

Device Structure

Contains multiple RS232 line drivers and receivers on a single chip. Supports full duplex transmission. Built with integrated protection circuitry for over-voltage and ESD. Surface-mount configuration for easy PCB assembly.

Performance Characteristics

High-speed data transmission up to 1 Mbps. Wide supply voltage range allows flexible design. Enhanced noise immunity due to 500 mV receiver hysteresis. Reliable operation across industrial temperature ranges. Low power consumption compared to older designs.

Application Environments

Used in industrial communication systems, PCs, embedded systems, data acquisition equipment, serial data interface boards. Suitable for environments requiring robust serial communications over RS232 standard in harsh temperature ranges.

Selection Guidelines

Choose for designs needing multi-channel RS232 transmission, high data rates, wide supply voltage range, and full duplex operations. Good fit for surface mount assemblies and space-constrained devices. Ensure the number of drivers/receivers and voltage specs meet your system requirement.

Usage Considerations

Verify supply voltage and temperature specs match your application. Surface-mount package needs proper PCB pad layout. Consider power dissipation if operating at maximum data rates. Use recommended ESD handling precautions during assembly.

Potential Equivalent/Replacement Models

There are equivalent or alternative models available. Detailed list:

MAX3237CAI+T

MAX3237EEAI+

MAX3237ECAI+

ICL3237ECAZ

MAX3237EIDBR

If you require alternatives not listed here or need help choosing the best substitute, please contact the Ariat-Tech sales team for further assistance.
