Manufacturer Part Number

HMC1034LP6GE

Description

3GHz Clock Generator IC with 1 input to 2 output capability. Packaged in a 40-VFQFN with exposed pad for better heat dissipation. Designed for high-speed, high-precision clock generation in a compact footprint.

Specifications

Maximum output frequency of 3GHz. Input clock signal supported. Ratio of input to output is 1 to 2. Operates on supply voltage from 3V to 5.2V. Single circuit device. Surface-mount design for PCB integration. Runs at temperatures from -40°C to 85°C. Package: 40-VFQFN, 6x6mm, MSL 1 unlimited.

Device Structure

Integrated PLL (Phase Locked Loop) included for frequency synthesis. No differential input, but differential output is supported. Divider function present, multiplier not available. Features an exposed pad for improved thermal management.

Performance Characteristics

High-speed clock generation up to 3GHz ensures precise timing for demanding applications. Low jitter and robust signal integrity. Stable operation over wide temperature range. Reliable performance with unlimited moisture sensitivity.

Application Environments

Ideal for communication infrastructure, data networking equipment, RF/microwave systems, and any application requiring high-frequency clock signals. Suitable for industrial, telecommunication, and test/measurement environments.

Selection Guidelines

Choose this model for applications needing high-frequency (up to 3GHz) clock outputs and 1:2 input/output ratio. Ensure power supply between 3V and 5.2V is available. Confirm compatibility with 40-VFQFN package and surface-mount assembly.

Usage Considerations

Ensure PCB layout enables efficient thermal dissipation from the exposed pad. Verify frequency and output requirements match the device capabilities. Confirm the device is operating within -40°C to 85°C. As this device is obsolete, plan for long-term availability and consider potential replacements.

Potential Equivalent/Replacement Models

The device status is obsolete, and Analog Devices recommends considering substitutes. ADF4356BCPZ is a potential alternative product with similar functionality. For a more complete list of alternative models, or if a direct replacement is not available, contact Ariat-Tech sales team through the website for support and guidance.
